Timken Part Number |
Shaft Size d |
Total Width |
Static Load Rating |
Dynamic Load Rating |
Inside Ring Outside Diameter |
Series |
Weight |
Seal Type |
Housing Construction |
| YAK 17 | Shaft Size d 0.669 in17 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.941 in23.9 mm | Series Industrial | Weight 1.0 lb0.4536 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 17 | Shaft Size d 0.669 in17 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.950 in24.1 mm | Series Standard | Weight 0.926 lb0.42 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 17 | Shaft Size d 0.669 in17 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.941 in23.9 mm | Series Industrial | Weight 1.0 lb0.4536 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 17 | Shaft Size d 0.669 in17 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.950 in24.1 mm | Series Standard | Weight 0.926 lb0.42 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 20 SGT | Shaft Size d 0.787 in20 mm | Total Width 1.311 in33.30 mm | Static Load Rating 1460 lbf6500 N | Dynamic Load Rating 3190 lbf14200 N | Inside Ring Outside Diameter 1.085 in27.5 mm | Series Industrial | Weight 1.494 lb0.6775 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 20 | Shaft Size d 0.787 in20 mm | Total Width 1.252 in31.8 mm | Static Load Rating 1460 lbf6500 N | Dynamic Load Rating 3190 lbf14200 N | Inside Ring Outside Diameter 1.122 in28.5 mm | Series Standard | Weight 1.257 lb0.57 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 20 SGT | Shaft Size d 0.787 in20 mm | Total Width 1.311 in33.30 mm | Static Load Rating 1460 lbf6500 N | Dynamic Load Rating 3190 lbf14200 N | Inside Ring Outside Diameter 1.085 in27.5 mm | Series Industrial | Weight 1.549 lb0.7027 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 20 | Shaft Size d 0.787 in20 mm | Total Width 1.252 in31.8 mm | Static Load Rating 1460 lbf6500 N | Dynamic Load Rating 3190 lbf14200 N | Inside Ring Outside Diameter 1.122 in28.5 mm | Series Standard | Weight 1.257 lb0.57 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 25 SGT | Shaft Size d 0.984 in25 mm | Total Width 1.469 in37.3 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.332 in33.8 mm | Series Industrial | Weight 1.967 lb0.8924 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 25 | Shaft Size d 0.984 in25 mm | Total Width 1.406 in35.7 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.316 in33.4 mm | Series Standard | Weight 1.676 lb0.76 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 25 SGT | Shaft Size d 0.984 in25 mm | Total Width 1.469 in37.3 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.332 in33.8 mm | Series Industrial | Weight 2.102 lb0.9535 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 25 | Shaft Size d 0.984 in25 mm | Total Width 1.406 in35.7 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.316 in33.4 mm | Series Standard | Weight 1.653 lb0.75 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 1 SGT | Shaft Size d 1 in25.4 mm | Total Width 1.469 in37.3 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.332 in33.8 mm | Series Industrial | Weight 1.967 lb0.8924 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 | Shaft Size d 1 in25.4 mm | Total Width 1.406 in35.7 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.316 in33.4 mm | Series Standard | Weight 1.676 lb0.76 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 SGT | Shaft Size d 1 in25.4 mm | Total Width 1.469 in37.3 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.332 in33.8 mm | Series Industrial | Weight 2.102 lb0.9535 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 | Shaft Size d 1 in25.4 mm | Total Width 1.406 in35.7 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.316 in33.4 mm | Series Standard | Weight 1.653 lb0.75 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 | Shaft Size d 1 in25.4 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 2.860 lb1.30 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 1/2 SGT | Shaft Size d 1 1/2 in38.1 mm | Total Width 2.031 in51.60 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.058 in52.3 mm | Series Industrial | Weight 5.459 lb2.4763 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 1/2 | Shaft Size d 1 1/2 in38.1 mm | Total Width 1.874 in47.6 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.068 in52.5 mm | Series Standard | Weight 4.079 lb1.85 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 1/2 SGT | Shaft Size d 1 1/2 in38.1 mm | Total Width 2.031 in51.60 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.058 in52.3 mm | Series Industrial | Weight 5.459 lb2.4763 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 1/2 | Shaft Size d 1 1/2 in38.1 mm | Total Width 1.874 in47.6 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.068 in52.5 mm | Series Standard | Weight 4.079 lb1.85 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| SAS 1 1/2 H | Shaft Size d 1 1/2 in38.1 mm | Total Width 1.874 in47.6 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.068 in52.5 mm | Series Standard | Weight 4.079 lb1.85 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 1/2 | Shaft Size d 1 1/2 in38.1 mm | Total Width 2.0000 in50.800 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 4.924 lb2.230 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 1/4S | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 2.985 lb1.3541 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 1/4 SGT | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.843 in46.8 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.064 lb1.8434 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 1/4 S | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| SAK 1 1/4 | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 1/4 S | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.689 in42.90 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 3.147 lb1.4275 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAS 1 1/4 SGT | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.843 in46.8 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.185 lb1.8981 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 1/4 S | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| SAS 1 1/4 | Shaft Size d 1 1/4 in31.8 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 1 1/8 SGT | Shaft Size d 1 1/8 in28.6 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 2.985 lb1.3541 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 1/8 | Shaft Size d 1 1/8 in28.6 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 1/8 SGT | Shaft Size d 1 1/8 in28.6 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 3.147 lb1.4275 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 1/8 | Shaft Size d 1 1/8 in28.6 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 1 11/16 SGT | Shaft Size d 1 11/16 in42.9 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.801 lb2.6311 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 11/16 | Shaft Size d 1 11/16 in42.9 mm | Total Width 2.0000 in50.800 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 11/16 SGT | Shaft Size d 1 11/16 in42.9 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.911 lb2.681 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 11/16 | Shaft Size d 1 11/16 in42.9 mm | Total Width 2.008 in51.00 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 11/16 | Shaft Size d 1 11/16 in42.9 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Industrial | Weight 7.240 lb3.28 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 15/16 SGT | Shaft Size d 1 15/16 in49.2 mm | Total Width 2.280 in57.9 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Industrial | Weight 7.182 lb3.2579 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 15/16 | Shaft Size d 1 15/16 in49.2 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Standard | Weight 5.6 lb2.54 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 15/16 SGT | Shaft Size d 1 15/16 in49.2 mm | Total Width 2.280 in57.9 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Industrial | Weight 7.305 lb3.3136 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 15/16 | Shaft Size d 1 15/16 in49.2 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Standard | Weight 5.6 lb2.54 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 15/16 | Shaft Size d 1 15/16 in49.2 mm | Total Width 2.157 in54.8 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 7.908 lb3.59 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 3/16 SGT | Shaft Size d 1 3/16 in30.2 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 2.985 lb1.3541 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 3/16 | Shaft Size d 1 3/16 in30.2 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 3/16 SGT | Shaft Size d 1 3/16 in30.2 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 3.147 lb1.4275 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 3/16 | Shaft Size d 1 3/16 in30.2 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 3/16 | Shaft Size d 1 3/16 in30.2 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 2.860 lb1.30 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 3/4 SGT | Shaft Size d 1 3/4 in44.5 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.801 lb2.6311 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 3/4 | Shaft Size d 1 3/4 in44.5 mm | Total Width 2.0000 in50.800 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 3/4 SGT | Shaft Size d 1 3/4 in44.5 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.911 lb2.681 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 3/4 | Shaft Size d 1 3/4 in44.5 mm | Total Width 2.008 in51.00 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 3/4 | Shaft Size d 1 3/4 in44.5 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Industrial | Weight 7.090 lb3.22 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 1 3/8 SGT | Shaft Size d 1 3/8 in34.9 mm | Total Width 1.843 in46.8 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.064 lb1.8434 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 3/8 | Shaft Size d 1 3/8 in34.9 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 3/8 SGT | Shaft Size d 1 3/8 in34.9 mm | Total Width 1.843 in46.8 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.185 lb1.8981 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 3/8 | Shaft Size d 1 3/8 in34.9 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 1 5/8 SGT | Shaft Size d 1 5/8 in41.3 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.801 lb2.6311 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 5/8 | Shaft Size d 1 5/8 in41.3 mm | Total Width 2.0000 in50.800 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 5/8 SGT | Shaft Size d 1 5/8 in41.3 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.911 lb2.681 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 5/8 | Shaft Size d 1 5/8 in41.3 mm | Total Width 2.008 in51.00 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 1 7/16 SGT | Shaft Size d 1 7/16 in36.5 mm | Total Width 1.843 in46.8 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.064 lb1.8434 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1 7/16 | Shaft Size d 1 7/16 in36.5 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1 7/16 SGT | Shaft Size d 1 7/16 in36.5 mm | Total Width 1.843 in46.8 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.185 lb1.8981 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1 7/16 | Shaft Size d 1 7/16 in36.5 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 1 7/16 | Shaft Size d 1 7/16 in36.5 mm | Total Width 1.874 in47.6 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.058 in52.3 mm | Series Industrial | Weight 4.512 lb2.05 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 30 SGT | Shaft Size d 1.181 in30 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 2.985 lb1.3541 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 30 | Shaft Size d 1.181 in30 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 30 SGT | Shaft Size d 1.181 in30 mm | Total Width 1.689 in42.90 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.587 in40.3 mm | Series Industrial | Weight 3.147 lb1.4275 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 30 | Shaft Size d 1.181 in30 mm | Total Width 1.563 in39.7 mm | Static Load Rating 2530 lbf11300 N | Dynamic Load Rating 4850 lbf21600 N | Inside Ring Outside Diameter 1.567 in39.8 mm | Series Standard | Weight 2.513 lb1.14 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 35 SGT | Shaft Size d 1.378 in35 mm | Total Width 1.843 in46.8 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.064 lb1.8434 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 35 | Shaft Size d 1.378 in35 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 35 SGT | Shaft Size d 1.378 in35 mm | Total Width 1.843 in46.8 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.844 in46.8 mm | Series Industrial | Weight 4.185 lb1.8981 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 35 | Shaft Size d 1.378 in35 mm | Total Width 1.780 in45.2 mm | Static Load Rating 3440 lbf15300 N | Dynamic Load Rating 6400 lbf28500 N | Inside Ring Outside Diameter 1.854 in47.1 mm | Series Standard | Weight 3.351 lb1.52 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 40 SGT | Shaft Size d 1.575 in40 mm | Total Width 2.031 in51.60 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.058 in52.3 mm | Series Industrial | Weight 5.459 lb2.4763 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 40 | Shaft Size d 1.575 in40 mm | Total Width 1.874 in47.6 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.068 in52.5 mm | Series Standard | Weight 4.079 lb1.85 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 40 SGT | Shaft Size d 1.575 in40 mm | Total Width 2.031 in51.60 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.058 in52.3 mm | Series Industrial | Weight 5.459 lb2.4763 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 40 | Shaft Size d 1.575 in40 mm | Total Width 1.874 in47.6 mm | Static Load Rating 4460 lbf19800 N | Dynamic Load Rating 8130 lbf36200 N | Inside Ring Outside Diameter 2.068 in52.5 mm | Series Standard | Weight 4.079 lb1.85 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 45 SGT | Shaft Size d 1.772 in45 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.801 lb2.6311 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 45 | Shaft Size d 1.772 in45 mm | Total Width 2.0000 in50.800 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 45 SGT | Shaft Size d 1.772 in45 mm | Total Width 2.063 in52.4 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Industrial | Weight 5.911 lb2.681 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 45 | Shaft Size d 1.772 in45 mm | Total Width 2.008 in51.00 mm | Static Load Rating 4600 lbf20500 N | Dynamic Load Rating 8160 lbf36300 N | Inside Ring Outside Diameter 2.280 in57.9 mm | Series Standard | Weight 4.542 lb2.06 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 50 SGT | Shaft Size d 1.969 in50 mm | Total Width 2.280 in57.9 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Industrial | Weight 7.182 lb3.2579 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 50 | Shaft Size d 1.969 in50 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Standard | Weight 5.6 lb2.54 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 50 SGT | Shaft Size d 1.969 in50 mm | Total Width 2.280 in57.9 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Industrial | Weight 7.305 lb3.3136 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 50 | Shaft Size d 1.969 in50 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Standard | Weight 5.6 lb2.54 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 1/2 | Shaft Size d 1/2 in12.7 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.941 in23.9 mm | Series Industrial | Weight 1.0 lb0.4536 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 1/2 | Shaft Size d 1/2 in12.7 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.950 in24.1 mm | Series Standard | Weight 0.926 lb0.42 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 1/2 | Shaft Size d 1/2 in12.7 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.941 in23.9 mm | Series Industrial | Weight 1.0 lb0.4536 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 1/2 | Shaft Size d 1/2 in12.7 mm | Total Width 1.189 in30.2 mm | Static Load Rating 1070 lbf4700 N | Dynamic Load Rating 2380 lbf10700 N | Inside Ring Outside Diameter 0.950 in24.1 mm | Series Standard | Weight 0.926 lb0.42 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 15/16 SGT | Shaft Size d 15/16 in23.8 mm | Total Width 1.469 in37.3 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.332 in33.8 mm | Series Industrial | Weight 1.967 lb0.8924 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 15/16 | Shaft Size d 15/16 in23.8 mm | Total Width 1.406 in35.7 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.316 in33.4 mm | Series Standard | Weight 1.676 lb0.76 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 15/16 SGT | Shaft Size d 15/16 in23.8 mm | Total Width 1.469 in37.3 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.332 in33.8 mm | Series Industrial | Weight 2.102 lb0.9535 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 15/16 | Shaft Size d 15/16 in23.8 mm | Total Width 1.406 in35.7 mm | Static Load Rating 1750 lbf7800 N | Dynamic Load Rating 3490 lbf15500 N | Inside Ring Outside Diameter 1.316 in33.4 mm | Series Standard | Weight 1.653 lb0.75 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAK 2 SGT | Shaft Size d 2 in50.8 mm | Total Width 2.374 in60.3 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 8.600 lb3.9009 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 2S | Shaft Size d 2 in50.8 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Standard | Weight 5.6 lb2.54 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| SAK 2 | Shaft Size d 2 in50.8 mm | Total Width 2.311 in58.70 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Standard | Weight 6.658 lb3.02 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 2 SGT | Shaft Size d 2 in50.8 mm | Total Width 2.374 in60.3 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 8.600 lb3.9009 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 2 S | Shaft Size d 2 in50.8 mm | Total Width 2.189 in55.60 mm | Static Load Rating 5210 lbf23200 N | Dynamic Load Rating 8740 lbf38900 N | Inside Ring Outside Diameter 2.474 in62.8 mm | Series Standard | Weight 5.6 lb2.54 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| SAS 2 | Shaft Size d 2 in50.8 mm | Total Width 2.311 in58.70 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Standard | Weight 6.658 lb3.02 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 2 | Shaft Size d 2 in50.8 mm | Total Width 2.157 in54.8 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 7.780 lb3.53 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YASM 2 1/2 | Shaft Size d 2 1/2 in63.5 mm | Total Width 2.875 in73.02 mm | Static Load Rating 9890 lbf44000 N | Dynamic Load Rating 15500 lbf69000 N | Inside Ring Outside Diameter 3.422 in86.9 mm | Series Industrial | Weight 16.106 lb7.31 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 2 1/4 SGT | Shaft Size d 2 1/4 in57.2 mm | Total Width 2.374 in60.3 mm | Static Load Rating 8080 lbf35900 N | Dynamic Load Rating 13100 lbf58200 N | Inside Ring Outside Diameter 3.011 in76.5 mm | Series Industrial | Weight 10.520 lb4.7718 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAS 2 1/4 SGT | Shaft Size d 2 1/4 in57.2 mm | Total Width 2.374 in60.3 mm | Static Load Rating 8080 lbf35900 N | Dynamic Load Rating 13100 lbf58200 N | Inside Ring Outside Diameter 3.011 in76.5 mm | Series Industrial | Weight 10.520 lb4.7718 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YASM 2 1/4 | Shaft Size d 2 1/4 in57.2 mm | Total Width 2.374 in60.3 mm | Static Load Rating 8080 lbf35900 N | Dynamic Load Rating 13100 lbf58200 N | Inside Ring Outside Diameter 3.011 in76.5 mm | Series Industrial | Weight 9.980 lb4.53 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 2 11/16 | Shaft Size d 2 11/16 in68.3 mm | Total Width 2.874 in73 mm | Static Load Rating 9890 lbf44000 N | Dynamic Load Rating 15500 lbf69000 N | Inside Ring Outside Diameter 3.422 in86.9 mm | Series Industrial | Weight 15.710 lb7.1259 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YASM 2 11/16 | Shaft Size d 2 11/16 in68.3 mm | Total Width 3.5000 in88.900 mm | Static Load Rating 10100 lbf44800 N | Dynamic Load Rating 15500 lbf68900 N | Inside Ring Outside Diameter 3.619 in91.9 mm | Series Industrial | Weight 25.240 lb11.45 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 2 15/16 | Shaft Size d 2 15/16 in74.6 mm | Total Width 3.252 in82.60 mm | Static Load Rating 10100 lbf44800 N | Dynamic Load Rating 15500 lbf68900 N | Inside Ring Outside Diameter 3.619 in91.9 mm | Series Industrial | Weight 18.780 lb8.5185 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAS 2 15/16 | Shaft Size d 2 15/16 in74.6 mm | Total Width 2.732 in69.4 mm | Static Load Rating 10100 lbf44800 N | Dynamic Load Rating 15500 lbf68900 N | Inside Ring Outside Diameter 3.619 in91.9 mm | Series Industrial | Weight 17.460 lb7.9197 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAS 2 15/16 H | Shaft Size d 2 15/16 in74.6 mm | Total Width 3.5000 in88.900 mm | Static Load Rating 10100 lbf44800 N | Dynamic Load Rating 15500 lbf68900 N | Inside Ring Outside Diameter 3.619 in91.9 mm | Series Industrial | Weight 18.560 lb8.4187 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YASM 2 15/16 | Shaft Size d 2 15/16 in74.6 mm | Total Width 3.5000 in88.900 mm | Static Load Rating 12200 lbf54200 N | Dynamic Load Rating 17900 lbf79400 N | Inside Ring Outside Diameter 3.873 in98.4 mm | Series Industrial | Weight 24.960 lb11.32 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 2 3/16 SGT | Shaft Size d 2 3/16 in55.6 mm | Total Width 2.374 in60.3 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 8.600 lb3.9009 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 2 3/16 | Shaft Size d 2 3/16 in55.6 mm | Total Width 2.311 in58.70 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Standard | Weight 6.658 lb3.02 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 2 3/16 SGT | Shaft Size d 2 3/16 in55.6 mm | Total Width 2.374 in60.3 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 8.600 lb3.9009 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 2 3/16 | Shaft Size d 2 3/16 in55.6 mm | Total Width 2.311 in58.70 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Standard | Weight 6.658 lb3.02 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YASM 2 3/16 | Shaft Size d 2 3/16 in55.6 mm | Total Width 2.374 in60.3 mm | Static Load Rating 8080 lbf35900 N | Dynamic Load Rating 13100 lbf58200 N | Inside Ring Outside Diameter 3.011 in76.5 mm | Series Industrial | Weight 9.898 lb4.49 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 2 7/16 SGT | Shaft Size d 2 7/16 in61.9 mm | Total Width 2.374 in60.3 mm | Static Load Rating 8080 lbf35900 N | Dynamic Load Rating 13100 lbf58200 N | Inside Ring Outside Diameter 3.011 in76.5 mm | Series Industrial | Weight 10.520 lb4.7718 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAS 2 7/16 SGT | Shaft Size d 2 7/16 in61.9 mm | Total Width 2.374 in60.3 mm | Static Load Rating 8080 lbf35900 N | Dynamic Load Rating 13100 lbf58200 N | Inside Ring Outside Diameter 3.011 in76.5 mm | Series Industrial | Weight 10.520 lb4.7718 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YASM 2 7/16 | Shaft Size d 2 7/16 in61.9 mm | Total Width 2.875 in73.02 mm | Static Load Rating 9890 lbf44000 N | Dynamic Load Rating 15500 lbf69000 N | Inside Ring Outside Diameter 3.422 in86.9 mm | Series Industrial | Weight 16.560 lb7.51 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| YAK 55 SGT | Shaft Size d 2.165 in55 mm | Total Width 2.374 in60.3 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 8.600 lb3.9009 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAK 55 | Shaft Size d 2.165 in55 mm | Total Width 2.311 in58.70 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Standard | Weight 6.658 lb3.02 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
| YAS 55 SGT | Shaft Size d 2.165 in55 mm | Total Width 2.374 in60.3 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Industrial | Weight 8.600 lb3.9009 Kg | Seal Type Shroud Seal | Housing Construction Two-Bolt Pillow Block |
| SAS 55 | Shaft Size d 2.165 in55 mm | Total Width 2.311 in58.70 mm | Static Load Rating 6570 lbf29200 N | Dynamic Load Rating 10800 lbf48100 N | Inside Ring Outside Diameter 2.747 in69.8 mm | Series Standard | Weight 6.658 lb3.02 Kg | Seal Type Narrow Shroud | Housing Construction Two-Bolt Pillow Block |
