Metric HMV Hydraulic Nut



Introduction

  • Designed to install and remove tapered bore bearings with minimal effort.
  • Allow better control of the bearing internal clearance reduction without damaging the bearing or other components.
  • Substantially reduces downtime during installation or removal of tapered bore bearings.


Description

  • Consist of a female threaded ring and a male ring with two O-ring seals.
  • All hydraulic nuts are supplied with:
    • Quick connection fittings (male 1/4 in. B.S.P. and female 3/8 in. N.P.T.).
    • Two pipe plugs 1/4 in. B.S.P.
    • One set of spare O-rings.



  • HMV - 10 through HMV - 40 have a Metric ISO fine thread profile.
  • HMV - 41 through HMV-236 have a Metric ISO trapezoidal thread.





Timken Part Number

  Threads B  C  D  E  Assembly Weight  Piston Length of Travel

Piston Area
HMV - 10 Threads B N/A M50x1.5 C N/A 114.0 mm D N/A 38.00 mm E N/A 86 mm Assembly Weight N/A 2.500 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 2900 mm²
HMV - 12 Threads B N/A M60x2 C N/A 125 mm D N/A 38.00 mm E N/A 94 mm Assembly Weight N/A 2.800 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 3200 mm²
HMV - 13 Threads B N/A M65x2 C N/A 135.0 mm D N/A 38.00 mm E N/A 101 mm Assembly Weight N/A 3.000 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 3500 mm²
HMV - 14 Threads B N/A M70x2 C N/A 140.0 mm D N/A 38.00 mm E N/A 107 mm Assembly Weight N/A 3.300 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 3900 mm²
HMV - 15 Threads B N/A M75x2 C N/A 145.0 mm D N/A 38.00 mm E N/A 112 mm Assembly Weight N/A 3.500 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 4100 mm²
HMV - 16 Threads B N/A M80x2 C N/A 150.0 mm D N/A 38.00 mm E N/A 117 mm Assembly Weight N/A 3.800 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 4200 mm²
HMV - 17 Threads B N/A M85x2 C N/A 155.0 mm D N/A 38.00 mm E N/A 122 mm Assembly Weight N/A 3.900 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 4400 mm²
HMV - 18 Threads B N/A M90x2 C N/A 160.0 mm D N/A 38.00 mm E N/A 127 mm Assembly Weight N/A 4.100 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 4800 mm²
HMV - 19 Threads B N/A M95x2 C N/A 165.0 mm D N/A 38.00 mm E N/A 133 mm Assembly Weight N/A 4.400 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 5000 mm²
HMV - 20 Threads B N/A M100x2 C N/A 170.0 mm D N/A 38.00 mm E N/A 138 mm Assembly Weight N/A 4.500 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 5200 mm²
HMV - 21 Threads B N/A M105x2 C N/A 175.0 mm D N/A 38.00 mm E N/A 143 mm Assembly Weight N/A 5.400 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 5400 mm²
HMV - 22 Threads B N/A M110x2 C N/A 180.0 mm D N/A 38.00 mm E N/A 149 mm Assembly Weight N/A 5.700 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 5700 mm²
HMV - 23 Threads B N/A M115x2 C N/A 185.0 mm D N/A 38.00 mm E N/A 154 mm Assembly Weight N/A 5.100 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 5900 mm²
HMV - 24 Threads B N/A M120x2 C N/A 190.0 mm D N/A 38.00 mm E N/A 159 mm Assembly Weight N/A 5.300 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 6100 mm²
HMV - 25 Threads B N/A M125x2 C N/A 195.0 mm D N/A 38.00 mm E N/A 164 mm Assembly Weight N/A 5.400 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 6300 mm²
HMV - 26 Threads B N/A M130x2 C N/A 200.0 mm D N/A 38.00 mm E N/A 170 mm Assembly Weight N/A 5.700 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 6500 mm²
HMV - 27 Threads B N/A M135x2 C N/A 205.0 mm D N/A 38.00 mm E N/A 175 mm Assembly Weight N/A 5.900 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 6700 mm²
HMV - 28 Threads B N/A M140x2 C N/A 210.0 mm D N/A 38.00 mm E N/A 180 mm Assembly Weight N/A 6.100 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 6900 mm²
HMV - 29 Threads B N/A M145x2 C N/A 215.0 mm D N/A 39.00 mm E N/A 186 mm Assembly Weight N/A 6.500 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 7300 mm²
HMV - 30 Threads B N/A M150x2 C N/A 220.0 mm D N/A 39.00 mm E N/A 190 mm Assembly Weight N/A 6.600 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 7500 mm²
HMV - 31 Threads B N/A M155x3 C N/A 225.0 mm D N/A 39.00 mm E N/A 198 mm Assembly Weight N/A 6.900 Kg Piston Length of Travel N/A 5 mm Piston Area N/A 8100 mm²
HMV - 32 Threads B N/A M160x3 C N/A 235.0 mm D N/A 40.00 mm E N/A 206 mm Assembly Weight N/A 7.700 Kg Piston Length of Travel N/A 6 mm Piston Area N/A 8600 mm²
HMV - 33 Threads B N/A M165x3 C N/A 240.0 mm D N/A 40.00 mm E N/A 209 mm Assembly Weight N/A 8.000 Kg Piston Length of Travel N/A 6 mm Piston Area N/A 9000 mm²
HMV - 34 Threads B N/A M170x3 C N/A 245.0 mm D N/A 41.00 mm E N/A 215 mm Assembly Weight N/A 8.400 Kg Piston Length of Travel N/A 6 mm Piston Area N/A 9500 mm²
HMV - 36 Threads B N/A M180x3 C N/A 255.0 mm D N/A 41.00 mm E N/A 227 mm Assembly Weight N/A 9.100 Kg Piston Length of Travel N/A 6 mm Piston Area N/A 10300 mm²
HMV - 38 Threads B N/A M190x3 C N/A 270.0 mm D N/A 42.00 mm E N/A 239 mm Assembly Weight N/A 10.800 Kg Piston Length of Travel N/A 7 mm Piston Area N/A 11500 mm²
HMV - 40 Threads B N/A M200x3 C N/A 280.0 mm D N/A 43.00 mm E N/A 251 mm Assembly Weight N/A 11.400 Kg Piston Length of Travel N/A 8 mm Piston Area N/A 12500 mm²
HMV - 41 Threads B N/A Tr205x4 C N/A 290.0 mm D N/A 43.00 mm E N/A 256 mm Assembly Weight N/A 12.200 Kg Piston Length of Travel N/A 8 mm Piston Area N/A 12900 mm²
HMV - 42 Threads B N/A Tr210x4 C N/A 295.0 mm D N/A 44.00 mm E N/A 262 mm Assembly Weight N/A 12.500 Kg Piston Length of Travel N/A 9 mm Piston Area N/A 13500 mm²
HMV - 43 Threads B N/A Tr215x4 C N/A 300.0 mm D N/A 44.00 mm E N/A 267 mm Assembly Weight N/A 13.000 Kg Piston Length of Travel N/A 9 mm Piston Area N/A 13800 mm²
HMV - 44 Threads B N/A Tr220x4 C N/A 305.0 mm D N/A 44.00 mm E N/A 273 mm Assembly Weight N/A 13.400 Kg Piston Length of Travel N/A 9 mm Piston Area N/A 14400 mm²
HMV - 45 Threads B N/A Tr225x4 C N/A 315.0 mm D N/A 45.00 mm E N/A 280 mm Assembly Weight N/A 14.600 Kg Piston Length of Travel N/A 9 mm Piston Area N/A 15200 mm²
HMV - 46 Threads B N/A Tr230x4 C N/A 320.0 mm D N/A 45.00 mm E N/A 285 mm Assembly Weight N/A 14.800 Kg Piston Length of Travel N/A 9 mm Piston Area N/A 15600 mm²
HMV - 47 Threads B N/A Tr235x4 C N/A 325.0 mm D N/A 46.00 mm E N/A 291 mm Assembly Weight N/A 16.000 Kg Piston Length of Travel N/A 10 mm Piston Area N/A 16200 mm²
HMV - 48 Threads B N/A Tr240x4 C N/A 330.0 mm D N/A 46.00 mm E N/A 296 mm Assembly Weight N/A 16.300 Kg Piston Length of Travel N/A 10 mm Piston Area N/A 16500 mm²
HMV - 50 Threads B N/A Tr250x4 C N/A 345.0 mm D N/A 46.00 mm E N/A 307 mm Assembly Weight N/A 17.600 Kg Piston Length of Travel N/A 10 mm Piston Area N/A 17800 mm²
HMV - 52 Threads B N/A Tr260x4 C N/A 355.0 mm D N/A 47 mm E N/A 319 mm Assembly Weight N/A 19.000 Kg Piston Length of Travel N/A 11 mm Piston Area N/A 18800 mm²
HMV - 54 Threads B N/A Tr270x4 C N/A 370.0 mm D N/A 48.00 mm E N/A 330 mm Assembly Weight N/A 20.400 Kg Piston Length of Travel N/A 12 mm Piston Area N/A 19700 mm²
HMV - 56 Threads B N/A Tr280x4 C N/A 380.0 mm D N/A 49.00 mm E N/A 341 mm Assembly Weight N/A 22.000 Kg Piston Length of Travel N/A 12 mm Piston Area N/A 21100 mm²
HMV - 58 Threads B N/A Tr290x4 C N/A 390.0 mm D N/A 49.00 mm E N/A 353 mm Assembly Weight N/A 22.500 Kg Piston Length of Travel N/A 13 mm Piston Area N/A 22600 mm²
HMV - 60 Threads B N/A Tr300x4 C N/A 405.0 mm D N/A 51.00 mm E N/A 364 mm Assembly Weight N/A 25.600 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 23600 mm²
HMV - 62 Threads B N/A Tr310x5 C N/A 415.0 mm D N/A 52 mm E N/A 375 mm Assembly Weight N/A 27.000 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 24900 mm²
HMV - 64 Threads B N/A Tr320x5 C N/A 430.0 mm D N/A 53.00 mm E N/A 387 mm Assembly Weight N/A 29.600 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 26300 mm²
HMV - 66 Threads B N/A Tr330x5 C N/A 440.0 mm D N/A 53.00 mm E N/A 397 mm Assembly Weight N/A 31.000 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 27000 mm²
HMV - 68 Threads B N/A Tr340x5 C N/A 450.0 mm D N/A 53.00 mm E N/A 408 mm Assembly Weight N/A 32.500 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 28400 mm²
HMV - 69 Threads B N/A Tr345x5 C N/A 455.0 mm D N/A 54.00 mm E N/A 414 mm Assembly Weight N/A 33.600 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 29400 mm²
HMV - 70 Threads B N/A Tr350x5 C N/A 465.0 mm D N/A 56.00 mm E N/A 420 mm Assembly Weight N/A 35.000 Kg Piston Length of Travel N/A 14 mm Piston Area N/A 30000 mm²
HMV - 72 Threads B N/A Tr360x5 C N/A 475.0 mm D N/A 56.00 mm E N/A 431 mm Assembly Weight N/A 37.000 Kg Piston Length of Travel N/A 15 mm Piston Area N/A 31300 mm²
HMV - 73 Threads B N/A Tr365x5 C N/A 482.0 mm D N/A 57.00 mm E N/A 436 mm Assembly Weight N/A 38.500 Kg Piston Length of Travel N/A 15 mm Piston Area N/A 31700 mm²
HMV - 74 Threads B N/A Tr370x5 C N/A 490.0 mm D N/A 57.00 mm E N/A 442 mm Assembly Weight N/A 39.200 Kg Piston Length of Travel N/A 16 mm Piston Area N/A 32800 mm²
HMV - 76 Threads B N/A Tr380x5 C N/A 500.0 mm D N/A 58.00 mm E N/A 452 mm Assembly Weight N/A 41.000 Kg Piston Length of Travel N/A 16 mm Piston Area N/A 33600 mm²
HMV - 77 Threads B N/A Tr385x5 C N/A 505.0 mm D N/A 58.00 mm E N/A 459 mm Assembly Weight N/A 42.000 Kg Piston Length of Travel N/A 16 mm Piston Area N/A 34700 mm²
HMV - 80 Threads B N/A Tr400x5 C N/A 525.0 mm D N/A 60.00 mm E N/A 475 mm Assembly Weight N/A 46.000 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 36700 mm²
HMV - 82 Threads B N/A Tr410x5 C N/A 535.0 mm D N/A 61.00 mm E N/A 486 mm Assembly Weight N/A 48.200 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 38300 mm²
HMV - 84 Threads B N/A Tr420x5 C N/A 545.0 mm D N/A 61.00 mm E N/A 498 mm Assembly Weight N/A 50.400 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 40000 mm²
HMV - 86 Threads B N/A Tr430x5 C N/A 555.0 mm D N/A 62 mm E N/A 508 mm Assembly Weight N/A 53.000 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 40800 mm²
HMV - 88 Threads B N/A Tr440x5 C N/A 565.0 mm D N/A 62 mm E N/A 519 mm Assembly Weight N/A 55.000 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 42500 mm²
HMV - 90 Threads B N/A Tr450x5 C N/A 580.0 mm D N/A 64.00 mm E N/A 530 mm Assembly Weight N/A 58.200 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 44100 mm²
HMV - 92 Threads B N/A Tr460x5 C N/A 590.0 mm D N/A 64.00 mm E N/A 541 mm Assembly Weight N/A 61.000 Kg Piston Length of Travel N/A 17 mm Piston Area N/A 45000 mm²
HMV - 94 Threads B N/A Tr470x5 C N/A 600.0 mm D N/A 65.00 mm E N/A 552 mm Assembly Weight N/A 63.700 Kg Piston Length of Travel N/A 18 mm Piston Area N/A 46900 mm²
HMV - 96 Threads B N/A Tr480x5 C N/A 612.0 mm D N/A 65.00 mm E N/A 563 mm Assembly Weight N/A 65.000 Kg Piston Length of Travel N/A 19 mm Piston Area N/A 48500 mm²
HMV - 98 Threads B N/A Tr490x5 C N/A 625.0 mm D N/A 66.00 mm E N/A 573 mm Assembly Weight N/A 69.000 Kg Piston Length of Travel N/A 19 mm Piston Area N/A 49800 mm²
HMV - 100 Threads B N/A Tr500x5 C N/A 635.0 mm D N/A 67.00 mm E N/A 585 mm Assembly Weight N/A 71.500 Kg Piston Length of Travel N/A 19 mm Piston Area N/A 52000 mm²
HMV - 102 Threads B N/A Tr510x6 C N/A 645.0 mm D N/A 68.00 mm E N/A 596 mm Assembly Weight N/A 75.000 Kg Piston Length of Travel N/A 20 mm Piston Area N/A 53300 mm²
HMV - 104 Threads B N/A Tr520x6 C N/A 657.0 mm D N/A 68.00 mm E N/A 606 mm Assembly Weight N/A 77.000 Kg Piston Length of Travel N/A 20 mm Piston Area N/A 54200 mm²
HMV - 106 Threads B N/A Tr530x6 C N/A 670.0 mm D N/A 69.00 mm E N/A 617 mm Assembly Weight N/A 80.000 Kg Piston Length of Travel N/A 21 mm Piston Area N/A 56200 mm²
HMV - 108 Threads B N/A Tr540x6 C N/A 680.0 mm D N/A 69.00 mm E N/A 629 mm Assembly Weight N/A 83.000 Kg Piston Length of Travel N/A 21 mm Piston Area N/A 58200 mm²
HMV - 110 Threads B N/A Tr550x6 C N/A 692.0 mm D N/A 70.00 mm E N/A 639 mm Assembly Weight N/A 86.000 Kg Piston Length of Travel N/A 21 mm Piston Area N/A 59200 mm²
HMV - 112 Threads B N/A Tr560x6 C N/A 705.0 mm D N/A 71.00 mm E N/A 650 mm Assembly Weight N/A 90.000 Kg Piston Length of Travel N/A 22 mm Piston Area N/A 61200 mm²
HMV - 114 Threads B N/A Tr570x6 C N/A 715.0 mm D N/A 72 mm E N/A 661 mm Assembly Weight N/A 93.000 Kg Piston Length of Travel N/A 23 mm Piston Area N/A 63200 mm²
HMV - 116 Threads B N/A Tr580x6 C N/A 725.0 mm D N/A 72 mm E N/A 671 mm Assembly Weight N/A 96.000 Kg Piston Length of Travel N/A 23 mm Piston Area N/A 64200 mm²
HMV - 120 Threads B N/A Tr600x6 C N/A 750.0 mm D N/A 73.00 mm E N/A 693 mm Assembly Weight N/A 100.000 Kg Piston Length of Travel N/A 23 mm Piston Area N/A 67400 mm²
HMV - 126 Threads B N/A Tr630x6 C N/A 780.0 mm D N/A 74.00 mm E N/A 726 mm Assembly Weight N/A 110.000 Kg Piston Length of Travel N/A 23 mm Piston Area N/A 72900 mm²
HMV - 130 Threads B N/A Tr650x6 C N/A 805.0 mm D N/A 75.00 mm E N/A 747 mm Assembly Weight N/A 116.000 Kg Piston Length of Travel N/A 23 mm Piston Area N/A 76200 mm²
HMV - 134 Threads B N/A Tr670x6 C N/A 825.0 mm D N/A 76.00 mm E N/A 768 mm Assembly Weight N/A 123.000 Kg Piston Length of Travel N/A 24 mm Piston Area N/A 79500 mm²
HMV - 138 Threads B N/A Tr690x6 C N/A 850.0 mm D N/A 77.00 mm E N/A 791 mm Assembly Weight N/A 130.000 Kg Piston Length of Travel N/A 25 mm Piston Area N/A 84200 mm²
HMV - 142 Threads B N/A Tr710x7 C N/A 870.0 mm D N/A 78.00 mm E N/A 812 mm Assembly Weight N/A 137.000 Kg Piston Length of Travel N/A 25 mm Piston Area N/A 87700 mm²
HMV - 150 Threads B N/A Tr750x7 C N/A 915.0 mm D N/A 79.00 mm E N/A 855 mm Assembly Weight N/A 150.000 Kg Piston Length of Travel N/A 25 mm Piston Area N/A 97000 mm²
HMV - 160 Threads B N/A Tr800x7 C N/A 970.0 mm D N/A 80 mm E N/A 908 mm Assembly Weight N/A 173.000 Kg Piston Length of Travel N/A 25 mm Piston Area N/A 104000 mm²
HMV - 170 Threads B N/A Tr850x7 C N/A 1020.0 mm D N/A 83.00 mm E N/A 962 mm Assembly Weight N/A 190.000 Kg Piston Length of Travel N/A 26 mm Piston Area N/A 114600 mm²
HMV - 180 Threads B N/A Tr900x7 C N/A 1070.0 mm D N/A 86.00 mm E N/A 1015 mm Assembly Weight N/A 210.000 Kg Piston Length of Travel N/A 30 mm Piston Area N/A 124000 mm²
HMV - 190 Threads B N/A Tr950x8 C N/A 1125.0 mm D N/A 86.00 mm E N/A 1069 mm Assembly Weight N/A 238.000 Kg Piston Length of Travel N/A 30 mm Piston Area N/A 135600 mm²
HMV - 200 Threads B N/A Tr1000x8 C N/A 1180.0 mm D N/A 88.00 mm E N/A 1122 mm Assembly Weight N/A 263.000 Kg Piston Length of Travel N/A 34 mm Piston Area N/A 145600 mm²
HMV - 212 Threads B N/A Tr1060x8 C N/A 1255.0 mm D N/A 95.00 mm E N/A 1184 mm Assembly Weight N/A 325.000 Kg Piston Length of Travel N/A 34 mm Piston Area N/A 161200 mm²
HMV - 216 Threads B N/A Tr1080x8 C N/A 1280.0 mm D N/A 100.00 mm E N/A 1206 mm Assembly Weight N/A 345.000 Kg Piston Length of Travel N/A 34 mm Piston Area N/A 167400 mm²
HMV - 224 Threads B N/A Tr1120x8 C N/A 1340.0 mm D N/A 106.00 mm E N/A 1250 mm Assembly Weight N/A 410.000 Kg Piston Length of Travel N/A 36 mm Piston Area N/A 178200 mm²
HMV - 236 Threads B N/A Tr1180x8 C N/A 1420.0 mm D N/A 115.00 mm E N/A 1320 mm Assembly Weight N/A 530.000 Kg Piston Length of Travel N/A 40 mm Piston Area N/A 189200 mm²
