Băng tải - Gàu tải > Cylindrical Roller Radial Bearings - Full Complement

Cylindrical Roller Radial Bearings - Full Complement





Timken Part Number

  Bore d  O.D. D Width B   DUR/DOR F/E  Static Load Rating Co  Dynamic Load Rating C1  Thermal Speed Ratings - Oil

Thermal Speed Ratings - Grease
NCF2922V Bore d N/A 110 mm4.3307 in O.D. D N/A 150.000 mm5.9055 in Width B N/A 24.000 mm0.9449 in DUR/DOR F/E N/A 141.100 mm5.5551 in Static Load Rating Co N/A 223 kN50100 lbf Dynamic Load Rating C1 N/A 146 kN32900 lbf Thermal Speed Ratings - Oil N/A 1200 rpm Thermal Speed Ratings - Grease N/A 1000 rpm
NCF2924V Bore d N/A 120 mm4.7244 in O.D. D N/A 165.000 mm6.4961 in Width B N/A 27.000 mm1.0630 in DUR/DOR F/E N/A 154.000 mm6.0630 in Static Load Rating Co N/A 297 kN66800 lbf Dynamic Load Rating C1 N/A 188 kN42400 lbf Thermal Speed Ratings - Oil N/A 1200 rpm Thermal Speed Ratings - Grease N/A 970 rpm
NCF2926V Bore d N/A 130 mm5.1181 in O.D. D N/A 180.000 mm7.0866 in Width B N/A 30.000 mm1.1811 in DUR/DOR F/E N/A 166.800 mm6.5669 in Static Load Rating Co N/A 361 kN81100 lbf Dynamic Load Rating C1 N/A 225 kN50600 lbf Thermal Speed Ratings - Oil N/A 1100 rpm Thermal Speed Ratings - Grease N/A 920 rpm
NCF2928V Bore d N/A 140 mm5.5118 in O.D. D N/A 190.000 mm7.4803 in Width B N/A 30.000 mm1.1811 in DUR/DOR F/E N/A 179.600 mm7.0709 in Static Load Rating Co N/A 389 kN87300 lbf Dynamic Load Rating C1 N/A 243 kN54700 lbf Thermal Speed Ratings - Oil N/A 1000 rpm Thermal Speed Ratings - Grease N/A 850 rpm
NCF2930V Bore d N/A 150 mm5.9055 in O.D. D N/A 210.000 mm8.2677 in Width B N/A 36.000 mm1.4173 in DUR/DOR F/E N/A 196.400 mm7.7323 in Static Load Rating Co N/A 506 kN114000 lbf Dynamic Load Rating C1 N/A 328 kN73800 lbf Thermal Speed Ratings - Oil N/A 1010 rpm Thermal Speed Ratings - Grease N/A 840 rpm
NCF2932V Bore d N/A 160 mm6.2992 in O.D. D N/A 220.000 mm8.6614 in Width B N/A 36.000 mm1.4173 in DUR/DOR F/E N/A 207.200 mm8.1575 in Static Load Rating Co N/A 540 kN121000 lbf Dynamic Load Rating C1 N/A 340 kN76300 lbf Thermal Speed Ratings - Oil N/A 940 rpm Thermal Speed Ratings - Grease N/A 790 rpm
NCF2934V Bore d N/A 170 mm6.6929 in O.D. D N/A 230.000 mm9.0551 in Width B N/A 36.000 mm1.4173 in DUR/DOR F/E N/A 218.000 mm8.5827 in Static Load Rating Co N/A 574 kN129000 lbf Dynamic Load Rating C1 N/A 350 kN78700 lbf Thermal Speed Ratings - Oil N/A 890 rpm Thermal Speed Ratings - Grease N/A 740 rpm
NCF2936V Bore d N/A 180 mm7.0866 in O.D. D N/A 250.000 mm9.8425 in Width B N/A 42.000 mm1.6535 in DUR/DOR F/E N/A 231.500 mm9.1142 in Static Load Rating Co N/A 711 kN160000 lbf Dynamic Load Rating C1 N/A 436 kN98000 lbf Thermal Speed Ratings - Oil N/A 850 rpm Thermal Speed Ratings - Grease N/A 710 rpm
NCF2938V Bore d N/A 190 mm7.4803 in O.D. D N/A 260.000 mm10.2362 in Width B N/A 42.000 mm1.6535 in DUR/DOR F/E N/A 244.000 mm9.6063 in Static Load Rating Co N/A 803 kN180000 lbf Dynamic Load Rating C1 N/A 487 kN109000 lbf Thermal Speed Ratings - Oil N/A 780 rpm Thermal Speed Ratings - Grease N/A 660 rpm
NCF1840V Bore d N/A 200 mm7.874 in O.D. D N/A 250.000 mm9.8425 in Width B N/A 24.000 mm0.9449 in DUR/DOR F/E N/A 237.500 mm9.3504 in Static Load Rating Co N/A 337 kN75700 lbf Dynamic Load Rating C1 N/A 188 kN42400 lbf Thermal Speed Ratings - Oil N/A 740 rpm Thermal Speed Ratings - Grease N/A 610 rpm
NCF2940V Bore d N/A 200 mm7.874 in O.D. D N/A 280.000 mm11.0236 in Width B N/A 48.000 mm1.8898 in DUR/DOR F/E N/A 261.100 mm10.2795 in Static Load Rating Co N/A 971 kN218000 lbf Dynamic Load Rating C1 N/A 587 kN132000 lbf Thermal Speed Ratings - Oil N/A 730 rpm Thermal Speed Ratings - Grease N/A 620 rpm
NCF1844V Bore d N/A 220 mm8.6614 in O.D. D N/A 270.000 mm10.6299 in Width B N/A 24.000 mm0.9449 in DUR/DOR F/E N/A 257.700 mm10.1457 in Static Load Rating Co N/A 370 kN83100 lbf Dynamic Load Rating C1 N/A 198 kN44400 lbf Thermal Speed Ratings - Oil N/A 670 rpm Thermal Speed Ratings - Grease N/A 550 rpm
NCF2944V Bore d N/A 220 mm8.6614 in O.D. D N/A 300.000 mm11.8110 in Width B N/A 48.000 mm1.8898 in DUR/DOR F/E N/A 282.100 mm11.1063 in Static Load Rating Co N/A 1070 kN239000 lbf Dynamic Load Rating C1 N/A 615 kN138000 lbf Thermal Speed Ratings - Oil N/A 650 rpm Thermal Speed Ratings - Grease N/A 550 rpm
NCF1852V Bore d N/A 260 mm10.2362 in O.D. D N/A 320.000 mm12.5984 in Width B N/A 28.000 mm1.1024 in DUR/DOR F/E N/A 307.000 mm12.0866 in Static Load Rating Co N/A 553 kN124000 lbf Dynamic Load Rating C1 N/A 292 kN65500 lbf Thermal Speed Ratings - Oil N/A 580 rpm Thermal Speed Ratings - Grease N/A 480 rpm
NCF2952V Bore d N/A 260 mm10.2362 in O.D. D N/A 360.000 mm14.1732 in Width B N/A 60.000 mm2.3622 in DUR/DOR F/E N/A 333.400 mm13.1260 in Static Load Rating Co N/A 1480 kN333000 lbf Dynamic Load Rating C1 N/A 837 kN188000 lbf Thermal Speed Ratings - Oil N/A 540 rpm Thermal Speed Ratings - Grease N/A 460 rpm
NCF2960V Bore d N/A 300 mm11.811 in O.D. D N/A 420.000 mm16.5354 in Width B N/A 72.000 mm2.8346 in DUR/DOR F/E N/A 390.000 mm15.3543 in Static Load Rating Co N/A 2260 kN508000 lbf Dynamic Load Rating C1 N/A 1260 kN284000 lbf Thermal Speed Ratings - Oil N/A 430 rpm Thermal Speed Ratings - Grease N/A 370 rpm
NCF1864V Bore d N/A 320.000 mm12.5984 in O.D. D N/A 400.000 mm15.7480 in Width B N/A 38.000 mm1.4961 in DUR/DOR F/E N/A 382.800 mm15.0709 in Static Load Rating Co N/A 900 kN202000 lbf Dynamic Load Rating C1 N/A 471 kN106000 lbf Thermal Speed Ratings - Oil N/A 460 rpm Thermal Speed Ratings - Grease N/A 380 rpm
NCF2964V Bore d N/A 320.000 mm12.5984 in O.D. D N/A 440.000 mm17.3228 in Width B N/A 72.000 mm2.8346 in DUR/DOR F/E N/A 410.500 mm16.1614 in Static Load Rating Co N/A 2400 kN540000 lbf Dynamic Load Rating C1 N/A 1300 kN293000 lbf Thermal Speed Ratings - Oil N/A 400 rpm Thermal Speed Ratings - Grease N/A 340 rpm
NCF1868V Bore d N/A 340.000 mm13.3858 in O.D. D N/A 420.000 mm16.5354 in Width B N/A 38.000 mm1.4961 in DUR/DOR F/E N/A 402.800 mm15.8583 in Static Load Rating Co N/A 953 kN214000 lbf Dynamic Load Rating C1 N/A 484 kN109000 lbf Thermal Speed Ratings - Oil N/A 430 rpm Thermal Speed Ratings - Grease N/A 360 rpm
NCF1876V Bore d N/A 380.000 mm14.9606 in O.D. D N/A 480.000 mm18.8976 in Width B N/A 46.000 mm1.8110 in DUR/DOR F/E N/A 457.300 mm18.0039 in Static Load Rating Co N/A 1350 kN304000 lbf Dynamic Load Rating C1 N/A 698 kN157000 lbf Thermal Speed Ratings - Oil N/A 370 rpm Thermal Speed Ratings - Grease N/A 310 rpm
NCF2976V Bore d N/A 380.000 mm14.9606 in O.D. D N/A 520.000 mm20.4724 in Width B N/A 82.000 mm3.2283 in DUR/DOR F/E N/A 487.300 mm19.1850 in Static Load Rating Co N/A 3360 kN756000 lbf Dynamic Load Rating C1 N/A 1790 kN402000 lbf Thermal Speed Ratings - Oil N/A 310 rpm Thermal Speed Ratings - Grease N/A 270 rpm
NCF1880V Bore d N/A 400.000 mm15.7480 in O.D. D N/A 500.000 mm19.6850 in Width B N/A 46.000 mm1.8110 in DUR/DOR F/E N/A 474.000 mm18.6614 in Static Load Rating Co N/A 1410 kN316000 lbf Dynamic Load Rating C1 N/A 713 kN160000 lbf Thermal Speed Ratings - Oil N/A 350 rpm Thermal Speed Ratings - Grease N/A 290 rpm
NCF1884V Bore d N/A 420.000 mm16.5354 in O.D. D N/A 520.000 mm20.4724 in Width B N/A 46.000 mm1.8110 in DUR/DOR F/E N/A 498.800 mm19.6378 in Static Load Rating Co N/A 1490 kN335000 lbf Dynamic Load Rating C1 N/A 733 kN165000 lbf Thermal Speed Ratings - Oil N/A 330 rpm Thermal Speed Ratings - Grease N/A 280 rpm
NCF1888V Bore d N/A 440.000 mm17.3228 in O.D. D N/A 540.000 mm21.2598 in Width B N/A 46.000 mm1.8110 in DUR/DOR F/E N/A 515.500 mm20.2953 in Static Load Rating Co N/A 1550 kN347000 lbf Dynamic Load Rating C1 N/A 746 kN168000 lbf Thermal Speed Ratings - Oil N/A 310 rpm Thermal Speed Ratings - Grease N/A 260 rpm
NCF1892V Bore d N/A 460.000 mm18.1102 in O.D. D N/A 580.000 mm22.8346 in Width B N/A 56.000 mm2.2047 in DUR/DOR F/E N/A 552.600 mm21.7559 in Static Load Rating Co N/A 2040 kN458000 lbf Dynamic Load Rating C1 N/A 1030 kN232000 lbf Thermal Speed Ratings - Oil N/A 290 rpm Thermal Speed Ratings - Grease N/A 250 rpm
NCF2992V Bore d N/A 460.000 mm18.1102 in O.D. D N/A 620.000 mm24.4094 in Width B N/A 95.000 mm3.7402 in DUR/DOR F/E N/A 578.500 mm22.7756 in Static Load Rating Co N/A 4610 kN1040000 lbf Dynamic Load Rating C1 N/A 2310 kN518000 lbf Thermal Speed Ratings - Oil N/A 240 rpm Thermal Speed Ratings - Grease N/A 220 rpm
NCF2996V Bore d N/A 480.000 mm18.8976 in O.D. D N/A 650.000 mm25.5906 in Width B N/A 100.000 mm3.9370 in DUR/DOR F/E N/A 615.200 mm24.2205 in Static Load Rating Co N/A 4910 kN110000 lbf Dynamic Load Rating C1 N/A 2570 kN579000 lbf Thermal Speed Ratings - Oil N/A 230 rpm Thermal Speed Ratings - Grease N/A 210 rpm
NCF18/500V Bore d N/A 500.000 mm19.6850 in O.D. D N/A 620.000 mm24.4094 in Width B N/A 56.000 mm2.2047 in DUR/DOR F/E N/A 593.300 mm23.3583 in Static Load Rating Co N/A 2210 kN496000 lbf Dynamic Load Rating C1 N/A 1070 kN241000 lbf Thermal Speed Ratings - Oil N/A 260 rpm Thermal Speed Ratings - Grease N/A 220 rpm
NCF29/500V Bore d N/A 500.000 mm19.6850 in O.D. D N/A 670.000 mm26.3780 in Width B N/A 100.000 mm3.9370 in DUR/DOR F/E N/A 630.900 mm24.8386 in Static Load Rating Co N/A 5060 kN1140000 lbf Dynamic Load Rating C1 N/A 2610 kN587000 lbf Thermal Speed Ratings - Oil N/A 220 rpm Thermal Speed Ratings - Grease N/A 200 rpm
NCF18/530V Bore d N/A 530.000 mm20.8661 in O.D. D N/A 650.000 mm25.5906 in Width B N/A 56.000 mm2.2047 in DUR/DOR F/E N/A 624.000 mm24.5669 in Static Load Rating Co N/A 2340 kN525000 lbf Dynamic Load Rating C1 N/A 1100 kN248000 lbf Thermal Speed Ratings - Oil N/A 240 rpm Thermal Speed Ratings - Grease N/A 210 rpm
NCF18/560V Bore d N/A 560.000 mm22.0472 in O.D. D N/A 680.000 mm26.7717 in Width B N/A 56.000 mm2.2047 in DUR/DOR F/E N/A 654.700 mm25.7756 in Static Load Rating Co N/A 2460 kN554000 lbf Dynamic Load Rating C1 N/A 1130 kN255000 lbf Thermal Speed Ratings - Oil N/A 230 rpm Thermal Speed Ratings - Grease N/A 190 rpm
NCF18/600V Bore d N/A 600.000 mm23.6220 in O.D. D N/A 730.000 mm28.7402 in Width B N/A 60.000 mm2.3622 in DUR/DOR F/E N/A 695.200 mm27.3701 in Static Load Rating Co N/A 2630 kN592000 lbf Dynamic Load Rating C1 N/A 1170 kN263000 lbf Thermal Speed Ratings - Oil N/A 210 rpm Thermal Speed Ratings - Grease N/A 180 rpm
NCF18/630V Bore d N/A 630.000 mm24.8031 in O.D. D N/A 780.000 mm30.7087 in Width B N/A 69.000 mm2.7165 in DUR/DOR F/E N/A 737.500 mm29.0354 in Static Load Rating Co N/A 3100 kN698000 lbf Dynamic Load Rating C1 N/A 1410 kN316000 lbf Thermal Speed Ratings - Oil N/A 200 rpm Thermal Speed Ratings - Grease N/A 170 rpm
NCF18/670V Bore d N/A 670.000 mm26.3780 in O.D. D N/A 820.000 mm32.2835 in Width B N/A 69.000 mm2.7165 in DUR/DOR F/E N/A 782.300 mm30.7992 in Static Load Rating Co N/A 3320 kN746000 lbf Dynamic Load Rating C1 N/A 1450 kN327000 lbf Thermal Speed Ratings - Oil N/A 190 rpm Thermal Speed Ratings - Grease N/A 160 rpm
NCF18/710V Bore d N/A 710.000 mm27.9528 in O.D. D N/A 870.000 mm34.2520 in Width B N/A 74.000 mm2.9134 in DUR/DOR F/E N/A 830.700 mm32.7047 in Static Load Rating Co N/A 3920 kN882000 lbf Dynamic Load Rating C1 N/A 1740 kN390000 lbf Thermal Speed Ratings - Oil N/A 170 rpm Thermal Speed Ratings - Grease N/A 150 rpm
NCF18/750V Bore d N/A 750.000 mm29.5276 in O.D. D N/A 920.000 mm36.2205 in Width B N/A 78.000 mm3.0709 in DUR/DOR F/E N/A 878.000 mm34.5669 in Static Load Rating Co N/A 4600 kN1030000 lbf Dynamic Load Rating C1 N/A 2080 kN467000 lbf Thermal Speed Ratings - Oil N/A 160 rpm Thermal Speed Ratings - Grease N/A 140 rpm
NCF18/800V Bore d N/A 800.000 mm31.4961 in O.D. D N/A 980.000 mm38.5827 in Width B N/A 82.000 mm3.2283 in DUR/DOR F/E N/A 935.000 mm36.8110 in Static Load Rating Co N/A 4930 kN1110000 lbf Dynamic Load Rating C1 N/A 2150 kN484000 lbf Thermal Speed Ratings - Oil N/A 150 rpm Thermal Speed Ratings - Grease N/A 130 rpm
