Cylindrical Roller Radial Bearings - HJ Series

Chi tiết sản phẩm

Clearance fit suggested for outer ring when housing is stationary relative to load.
Tight transition fit suggested if housing rotates relative to load.
Consult your Timken representative for oscillating applications (e.g., low radial-clearance concerns).
Unmarked end of outer ring should be assembled against housing shoulder to clear maximum allowed housing fillet (r_{as max}).
Meets Military Standard MS 51961.

Timken Part Number	Shaft Diameter (F_w)	Dimension D	Dimension C/B	Static Load Rating C_o	Dynamic Load Rating C₁	Thermal Speed Ratings - Oil	Thermal Speed Ratings - Grease
HJ-607632	Shaft Diameter (F_w) N/A 95.25 mm3.75 in	Dimension D N/A 120.650 mm4.7500 in	Dimension C/B N/A 50.80 mm2.00 in	Static Load Rating C_o N/A 398 kN89400 lbf	Dynamic Load Rating C₁ N/A 193 kN43300 lbf	Thermal Speed Ratings - Oil N/A 3700 rpm	Thermal Speed Ratings - Grease N/A 3300 rpm
HJ-648032	Shaft Diameter (F_w) N/A 101.60 mm4.00 in	Dimension D N/A 127.000 mm5.0000 in	Dimension C/B N/A 50.80 mm2.00 in	Static Load Rating C_o N/A 428 kN96200 lbf	Dynamic Load Rating C₁ N/A 201 kN45100 lbf	Thermal Speed Ratings - Oil N/A 3500 rpm	Thermal Speed Ratings - Grease N/A 3100 rpm
HJ-688432	Shaft Diameter (F_w) N/A 107.95 mm4.25 in	Dimension D N/A 133.350 mm5.2500 in	Dimension C/B N/A 50.80 mm2.00 in	Static Load Rating C_o N/A 444 kN99900 lbf	Dynamic Load Rating C₁ N/A 203 kN45700 lbf	Thermal Speed Ratings - Oil N/A 3300 rpm	Thermal Speed Ratings - Grease N/A 2900 rpm
HJ-729636	Shaft Diameter (F_w) N/A 114.30 mm4.50 in	Dimension D N/A 152.400 mm6.0000 in	Dimension C/B N/A 57.15 mm2.25 in	Static Load Rating C_o N/A 517 kN116000 lbf	Dynamic Load Rating C₁ N/A 285 kN64000 lbf	Thermal Speed Ratings - Oil N/A 3200 rpm	Thermal Speed Ratings - Grease N/A 2800 rpm
HJ-729640	Shaft Diameter (F_w) N/A 114.30 mm4.50 in	Dimension D N/A 152.400 mm6.0000 in	Dimension C/B N/A 63.50 mm2.50 in	Static Load Rating C_o N/A 599 kN135000 lbf	Dynamic Load Rating C₁ N/A 320 kN71900 lbf	Thermal Speed Ratings - Oil N/A 3200 rpm	Thermal Speed Ratings - Grease N/A 2800 rpm
HJ-8010432	Shaft Diameter (F_w) N/A 127.00 mm5.00 in	Dimension D N/A 165.100 mm6.5000 in	Dimension C/B N/A 50.80 mm2.00 in	Static Load Rating C_o N/A 517 kN116000 lbf	Dynamic Load Rating C₁ N/A 278 kN62400 lbf	Thermal Speed Ratings - Oil N/A 2800 rpm	Thermal Speed Ratings - Grease N/A 2400 rpm
HJ-8010436	Shaft Diameter (F_w) N/A 127.00 mm5.00 in	Dimension D N/A 165.100 mm6.5000 in	Dimension C/B N/A 57.15 mm2.25 in	Static Load Rating C_o N/A 590 kN133000 lbf	Dynamic Load Rating C₁ N/A 308 kN69200 lbf	Thermal Speed Ratings - Oil N/A 2800 rpm	Thermal Speed Ratings - Grease N/A 2500 rpm
HJ-8010440	Shaft Diameter (F_w) N/A 127.00 mm5.00 in	Dimension D N/A 165.100 mm6.5000 in	Dimension C/B N/A 63.50 mm2.50 in	Static Load Rating C_o N/A 684 kN154000 lbf	Dynamic Load Rating C₁ N/A 345 kN77600 lbf	Thermal Speed Ratings - Oil N/A 2800 rpm	Thermal Speed Ratings - Grease N/A 2500 rpm
HJ-8811240	Shaft Diameter (F_w) N/A 139.70 mm5.50 in	Dimension D N/A 177.800 mm7.0000 in	Dimension C/B N/A 63.50 mm2.50 in	Static Load Rating C_o N/A 697 kN157000 lbf	Dynamic Load Rating C₁ N/A 342 kN76900 lbf	Thermal Speed Ratings - Oil N/A 2600 rpm	Thermal Speed Ratings - Grease N/A 2300 rpm
HJ-8811248	Shaft Diameter (F_w) N/A 139.70 mm5.50 in	Dimension D N/A 177.800 mm7.0000 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 883 kN198000 lbf	Dynamic Load Rating C₁ N/A 411 kN92400 lbf	Thermal Speed Ratings - Oil N/A 2500 rpm	Thermal Speed Ratings - Grease N/A 2200 rpm
HJ-9211648	Shaft Diameter (F_w) N/A 146.05 mm5.75 in	Dimension D N/A 184.150 mm7.2500 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 918 kN206000 lbf	Dynamic Load Rating C₁ N/A 419 kN94200 lbf	Thermal Speed Ratings - Oil N/A 2400 rpm	Thermal Speed Ratings - Grease N/A 2100 rpm
HJ-9612040	Shaft Diameter (F_w) N/A 152.40 mm6.00 in	Dimension D N/A 190.500 mm7.5000 in	Dimension C/B N/A 63.50 mm2.50 in	Static Load Rating C_o N/A 777 kN175000 lbf	Dynamic Load Rating C₁ N/A 364 kN81800 lbf	Thermal Speed Ratings - Oil N/A 2300 rpm	Thermal Speed Ratings - Grease N/A 2000 rpm
HJ-9612048	Shaft Diameter (F_w) N/A 152.40 mm6.00 in	Dimension D N/A 190.500 mm7.5000 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 984 kN221000 lbf	Dynamic Load Rating C₁ N/A 438 kN98400 lbf	Thermal Speed Ratings - Oil N/A 2200 rpm	Thermal Speed Ratings - Grease N/A 2000 rpm
HJ-10412840	Shaft Diameter (F_w) N/A 165.10 mm6.50 in	Dimension D N/A 203.200 mm8.0000 in	Dimension C/B N/A 63.50 mm2.50 in	Static Load Rating C_o N/A 832 kN187000 lbf	Dynamic Load Rating C₁ N/A 376 kN84600 lbf	Thermal Speed Ratings - Oil N/A 2100 rpm	Thermal Speed Ratings - Grease N/A 1800 rpm
HJ-10412848	Shaft Diameter (F_w) N/A 165.10 mm6.50 in	Dimension D N/A 203.200 mm8.0000 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 1050 kN237000 lbf	Dynamic Load Rating C₁ N/A 452 kN102000 lbf	Thermal Speed Ratings - Oil N/A 2000 rpm	Thermal Speed Ratings - Grease N/A 1800 rpm
HJ-11614648	Shaft Diameter (F_w) N/A 184.15 mm7.25 in	Dimension D N/A 231.775 mm9.1250 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 1130 kN253000 lbf	Dynamic Load Rating C₁ N/A 524 kN118000 lbf	Thermal Speed Ratings - Oil N/A 1800 rpm	Thermal Speed Ratings - Grease N/A 1600 rpm
HJ-12415448	Shaft Diameter (F_w) N/A 196.85 mm7.75 in	Dimension D N/A 244.475 mm9.6250 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 1210 kN271000 lbf	Dynamic Load Rating C₁ N/A 543 kN122000 lbf	Thermal Speed Ratings - Oil N/A 1600 rpm	Thermal Speed Ratings - Grease N/A 1400 rpm
HJ-13216248	Shaft Diameter (F_w) N/A 209.55 mm8.25 in	Dimension D N/A 257.175 mm10.1250 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 1290 kN290000 lbf	Dynamic Load Rating C₁ N/A 563 kN126000 lbf	Thermal Speed Ratings - Oil N/A 1500 rpm	Thermal Speed Ratings - Grease N/A 1300 rpm
HJ-14017048	Shaft Diameter (F_w) N/A 222.25 mm8.75 in	Dimension D N/A 269.875 mm10.6250 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 1370 kN308000 lbf	Dynamic Load Rating C₁ N/A 581 kN131000 lbf	Thermal Speed Ratings - Oil N/A 1400 rpm	Thermal Speed Ratings - Grease N/A 1200 rpm
HJ-14817848	Shaft Diameter (F_w) N/A 234.95 mm9.25 in	Dimension D N/A 282.575 mm11.1250 in	Dimension C/B N/A 76.20 mm3.00 in	Static Load Rating C_o N/A 1350 kN326000 lbf	Dynamic Load Rating C₁ N/A 599 kN145000 lbf	Thermal Speed Ratings - Oil N/A 1300 rpm	Thermal Speed Ratings - Grease N/A 1200 rpm
